• Dedicate VGA output design for LCD/DLP projectors • VGA output with 20 frames per second no flickering any more • Near A3 capture size , Light and compact 4.5kg only • Vivid color reprodution Life time Dual cold cathode lamp • 80X Zoom ( Optical / Digital / Mechanical )
SPECIFICATIONS
PS 550
Pick-up Device
1/3" progress scan CCD
Total Pixels
1077(H) X 788 (V)
Effective Pixels
1024(H) X 768 (V)
Frame Rate
20 Frames / sec
White Balance
Auto / Manual
Exposure
Auto / Manual
Digital Zoom
1~4X
Image Mode
Photo / Text / Inverse / Mono
Image Flip
0¢X / 180¢X Selectable
Freeze
Yes
Analog RGB Output
XGA 75Hz / SVGA 75Hz
C-Video Output
NTSC / PAL
S-Video Output
NTSC / PAL
Storage : Internal
32 Frames / External : PC card type II (Optional 5 in one memory Adapter¡GSD/SM/MS/MSPRO/MMC)
Shooting Area
400mm X 300mm(max.) / 38mm X 28.5mm(min.)
Macro mode
36 x 27 mm (min.)
Microscope
Eyepiece £r23.2 Sleve
Zooming
80X Zoom ( Optical / Digital / Mechanical )
Focusing
Auto / Manual
Lamp type
Cold Cathode Lamp
Backlight
A4 / 268 x 208 mm
VGA Input
HD-SUB 15 Pins female
Mouse Pointing
Standard PS2 Mouse
Mic. Input
Stereo Mini-Jack
RS232C
D-SUB 9Pin Male
VGA Output
HD-SUB 15 Pins female
DVI
Digital & Analog Receptacle Connector ( DVI-I )
DC12V Output
DC Jack, 500mA
Dimension
Operating 640(L) X 350(W) X 650(H) , Folded 510(L) X 350(W) X 130(H)
